Sinter Diamond Wire Saw for Ultra High Strength Concrete & Pure Metal Cutting

Short Description:

Diamond wire saws are widely used in the reform and dismantling of bridges, high-altitude and underwater buildings. They can be remotely controlled from a safe location to complete precise cutting in dangerous environments, making work easier and safer!


  • Model: SW-HPAA110
  • Diameter: 11mm / 11.5mm
  • Production Process: Vacuum Sintering
  • Number of Beads Per Meter: 40
  • Coating: Rubber + Spring
  • Cutting Speed: 15-22 m/s
  • Weight: 50m-31kg / 50m-33kg
  • Product Detail

    Product Tags

    Description

    1.  Application: suitable for pouring construction, beams, pillars, supporting structures, steel components of bridge construction or tall tower cutting. Meet the cutting of concrete grade greater than or equal to M350.

    2. The product is brazed beads ( with multi-layer diamond ) plus spring and rubber coating, with high structural strength, high wear resistance of rubber, and not easy to wear, high cutting speed, long life span.



    Parameter

    Product Code Diameter Production Process Number of Beads Coating Cutting Speed Weight
    mm pcs / meter
    SW-HPAA110 11 Vacuum Sintering 40 Rubber + Spring 15-22m/s 50m-31kg
    SW-HPAA115 11.5 Vacuum Sintering 40 Rubber + Spring 15-22m/s 50m-33kg
    SW-HPAAA110 10.5 Vacuum Brazing 44 Rubber + Spring 22-28m/s 50m-29kg
    SW-HPAAA115 11.5 Vacuum Brazing 44 Rubber + Spring 22-28m/s 50m-31kg

    Precautions for Use

    1. Please read the product instructions carefully before using the product for the first time.

    2. This product is designed for wet cutting, and the cutting area is fully cooled, which is beneficial to achieve the balance of high speed and long life of the rope.

    3.  When working, the test cutting speed needs to increase from slow to fast, and the operator needs to keep a safe distance.

    The wire saw is designed for the mining and processing of high-hardness marble, and provides different solutions for different low-abrasive hard limestone, hard marble and high-abrasive hard marble.
    Diamond wire saws are widely used in the reform and dismantling of bridges, high-altitude and underwater buildings.
