Arix Diamond Segment for Core Drill Bits Drilling for concrete

Short Description:

The arix diamond segment have different production processes for hot-pressing sintering and pressureless sintering. At the same time, we distinguish different versions of ultimate version, high-quality version, and standard version. Engineers can make product recommendations based on your processing conditions analysis.


  • Product Code: AR-PC152
  • Diamater: 152mm ( 6 inch)
  • Welding Method: Laser welding / High frequency welding / flame welding
  • Segment Height: 10/12mm
  • Segment Thickness: 3.5/4mm
  • Number of welding segments ( low power ): 11
  • Number of welding segments ( high power ): 13
  • Product Detail

    Product Tags

    Description

    1. The diamond particles arranged in the array are staggered in the length and height directions, the protrusion number of diamond particles per unit time is the same, the force of the diamond particles is balanced, and the drilling process is stable.

    2. Diamond particles arranged in an array reduce mutual interference, increase chip holding space, and effectively reduce cutting heat and non-cutting power consumption. Compared with disordered arrangement, sharpness and lifespan are significantly improved.

    3.  The arix diamond cutting segment have different production processes for hot-pressing sintering and pressureless sintering. At the same time, we distinguish different versions of ultimate version, high-quality version, and standard version. Engineers can make product recommendations based on your processing conditions analysis.

    Parameter

    Product Code Diameter
    (inch)
    Diameter
    (mm)
    Segment Type Segment Thickness
    (mm)
    Segment Height
    (mm)
    Welding Method Number of Welding Segment
    AR-PC050 1-15/16" 50 Diamond Arranged 3/3.5 10/11 Laser Welding / High Frequency Welding / Flame Welding Low power High power
    AR-PC052 2" 52 3/3.5 10/11
    AR-PC054 2-1/8" 54 3/3.5 10/11
    AR-PC060 2-1/4" 60 3/3.5 10/11
    AR-PC064 2-1/2" 64 3/3.5 10/11
    AR-PC068 2-5/8" 68 3/3.5 10/11
    AR-PC070 2-3/4" 70 3/3.5 10/11
    AR-PC076 3" 76 3/3.5 10/11
    AR-PC081 3-1/4" 81 3/3.5 10/11
    AR-PC085 3-3/8" 85 3/3.5 10/11
    AR-PC090 3-1/2" 90 3/3.5 10/11
    AR-PC095 3-3/4" 95 3/3.5 10/11
    AR-PC0102 4" 102 3/3.5 10/11
    AR-PC0106 4-1/8" 106 3/3.5 10/11 10
    AR-PC0110 4-3/8" 110 3/3.5 10/11 10
    AR-PC0112 4-3/8" 112 3/3.5 10/11 10
    AR-PC0122 4-3/4" 122 3/3.5 10/11 11
    AR-PC0127 5" 127 3/3.5 10/11 10  11
    AR-PC0132 5-1/4" 132 3/3.5 10/11 10  11
    AR-PC0142 5-5/8" 142 3/3.5 10/11 10  12
    AR-PC0145 5-3/4" 145 3/3.5 10/11 11  12
    AR-PC0152 6" 152 3.5/4 10/11 11  13
    AR-PC0162 6-3/8" 162 3.5/4 10/11 12  14
    AR-PC0165 6-1/2" 165 3.5/4 10/11 12  14
    AR-PC0172 6-3/4" 172 3.5/4 10/11 13  15
    AR-PC0182 7-1/8" 182 3.5/4 10/11 13  15
    AR-PC0192 7-1/2" 192 3.5/4 10/11 13  16
    AR-PC0202 8" 202 3.5/4 10/11 14  16
    AR-PC0205 8-1/8" 205 3.5/4 10/11 14  16

    Precautions for use

    1. Before welding, please confirm the internal and external diameter of the corresponding welding segment and the internal and external diameter of the steel blank, accurately control the position of brazing butt joint, and prevent welding eccentricity and inclination, which will reduce the drilling efficiency and lifespan.

    2. After the welding is completed, remove the surface stains. The welding strength is tested according to the strength standard in DIN EN 13236. The short arc-shaped diamond segment is tested with the force part as the middle part. For the standard strength test operation, please refer to the product instructions.

    3. This arix diamond cutter segment is designed for wet drilling, and the drilling area is fully cooled, which is beneficial to achieve the balance of high speed and life of the core drill. When a large amount of steam is released from the drilling area, it indicates that the bit is seriously overheated. Pressure water supply must be provided.

    Diamond particles arranged in an array reduce mutual interference, increase chip holding space, and effectively reduce cutting heat and non-cutting power consumption.
